Designed using the Legris push-in technology, this range is produced with specific applications in mind, hence its:
- emphasis on safety : the tube cannot be disconnected without using a special tool.
- nitrile seals on nut assemblies.
- sealing of tube by 2 “O” rings in addition to the gripping teeth.
The characteristics provide a perfect component for such applications as:
- lubrication curcuits on industrial machinery : wood industry, textile, paper, cement industry...
- lubrication on industrial equipment and vehicles (trucks)
- lubrication on public works vehicles (mobile cranes) and agricultural equipment
Technical Specification
Reliable performance is dependent upon the tube being used, ambient temperature and fluid conveyed together with the component materials of the fitting.
|
Suitable Fluids
|
Lubricating oils, liquid and viscous greases, oil sprays.
|
|
Working Pressure
|
Up to 60 bar dependant upon the working temperature and the type of tube used.
|
|
Working Temperature
|
-40°C to +120°C dependent upon the material and the O.D. of the tube used.
|
|
Materials of Construction
|
Brass
Nitrile Rubber ‘O’ rings and seals
|
|
Reliable Performance
- sealing effected by two ‘O’ rings located in front of the gripping mechanism and nitrile seals on nut assemblies
- full flow : no flow restriction
- strong robust brass construction
Models adapted to the Users Requirements
- stud, elbow fittings
- BSP tapered threads, metric tapered threads, metric parallel threads
Immediate Connection combined with Safety of the Installation
- instant manual connection without tools.
- disconnection impossible without the use of a spanner
A Perfect Component for Industrial Lubrication Applications
- industrial machinery and equipment
- heavy duty vehicles
- public works or agricultural equipment
|
